30" OLED Transparent Display | Commercial-Grade Transparent Screen
MODEL: HT300OL-D01
SERVICES
- Accountability: Every unit ships standard with CE/FCC/RoHS certification. UL/CCC/EAC certification can be arranged upon request — additional cost and lead time apply depending on the specific standard; please contact us for a quote before ordering.
- Return Policy: 12-month warranty with remote troubleshooting first, followed by free replacement and expedited reshipment once a hardware fault is confirmed.
- Lead Time: 2–3 weeks for standard products, 4–6 weeks for custom orders, and 6–8 weeks for bulk orders of 500+ units, with clear scheduling confirmed before order placement.
- Customer Support: 24/7 engineering support with a direct WhatsApp link on the website, ensuring fast responses across time zones without waiting on email.
- Production Capacity: Monthly production capacity: 12,000+ units (customizable specs), supporting both small-batch prototyping and large-volume orders.
- Inventory & Lead Time Assurance: We maintain safety stock of common panel sizes and standard components to buffer against supply chain fluctuations. For repeat orders, we offer scheduled/forecasted production slots to guarantee on-time delivery.
Need customized solution?
Our engineering team is always ready to provide you with professional technical support and flexible customized services.
Understand light customization servicesTechnical Specifications
| 30 inch OLED Transparent Display Product model: HT300OL-D01 | |||
|---|---|---|---|
| Disclaimer: The final interpretation of all information content contained in this document belongs to the company. All unauthorized reproduction is prohibited. This document contains parameter data for standard‑version models only, not representing all parameters of the whole product series. Actual parameters shall be subject to the formal model confirmation signed with sales. | |||
| Ⅰ、Product images | |||
| ‑(Product picture placement area)‑ | |||
| Ⅱ、Technical parameters | |||
| Display parameters | |||
| Panel size | 30" | ||
| Panel type | OLED | ||
| Display area | 664.29 mm * 373.48 mm | ||
| Overall dimensions(width x height x thickness) | 676.09mm x 387.48mm x 1.6mm | ||
| Transmittance | 43% | ||
| Viewing Angle | 178 °, 178 ° | ||
| Static contrast(transmission) | 100,000:1 (Typ.) | ||
| Dynamic contrast(transmission) | 200,000:1 (Typ.) | ||
| Splice seams | Single side 5.9mm, double side 12mm, overall single side patchwork 5.9/5.9/5.9/8.1(left/right/top/bottom) | ||
| Screen scale | 16:9 | ||
| Brightness | 200‑600 nit | ||
| Best resolution | 1366 * 768 | ||
| Screen Life | ≥ 30,000 hours | ||
| Power | ≦150W | ||
| Display colors | 10‑bit, 1.07B (1B= billion) | ||
| Speakers | 8 Ω / 5 w * 2 | ||
| Screen weight | 1.04kg | ||
| Gross weight of the machine | To be determined | ||
| Environment | |||
| Operating temperature | 1℃‑45℃ | ||
| Working humidity | 30% ~ 80% | ||
| Run time | 18 hours X7 days | ||
| Ambient height (Altitude) | 0‑5000m | ||
| Response time | 8ms | ||
| Operating voltage | 100V‑240VAC,50/60Hz | ||
| Fit method | Frame sticker | ||
| Fitting method (optional) | Full fit | ||
| Drive board card | |||
| Input interface‑HDMI IN | HDMI IN | ||
| USB | USB 2.0 | ||
| DP | DP IN | ||
| Weight of drive board | 0.4 kg | ||
| Control signal IN | RS232 serial port (RJ45) | ||
| Control signal OUT | RS232 serial port (RJ45) | ||
| Features | Band splice function | ||
| Protection | Anti‑residual shadow, anti‑burn, repair function | ||
| Touch screen parameters (optional) | |||
| Touch technology | Capacitive touch technology | ||
| Positioning accuracy | 3mm | ||
| Mounting method | Built‑in one‑piece | ||
| Writing style | Fingers ≥5mm | ||
| Touch count | 10 point touch writing | ||
| Writing screen Media | 5‑8mm tempered high permeability glass | ||
| Response speed | ≤5ms | ||
| Computer drive | no‑drive | ||
| Means of communication | USB | ||
| Service life | ≥60 million times | ||
| PC Configuration (optional) | |||
| Motherboard CPU | Intel Core CPU 4th / 6th / 7th / 8th / 10th generation ‑ Core i3/i5/i7 (optional) | ||
| Memory | 4G/8G/ 16G‑DDR3 (optional) | ||
| Hard drive | SSD120G/240G/480‑HDD500G/1T/2T (optional) | ||
| Core Display | Intel HD Graphics 4000 | ||
| Backplane I/O | 1 x DC_IN power port, 1 x HDMI port, 1 x VGA port, 2 x USB3.0 port, 1 x LAN_RJ port, 2 x USB2.0 port, 1 x Mic (input), 1 x PHONE (output) | ||
| Operating system | Windows7/ Windows10 operating system | ||
| Android configuration (optional) | |||
| Motherboard model | 3288/3399 | ||
| Memory | 2G/4G/8G optional | ||
| Storage | 8G/16G/32G/64 optional | ||
| Ports | 1 x USB2.0, 1 x USB3.0, 1 x HDMI_OUT, 1 x LAN_RJ, 1 x WIFI | ||
| Packing list | |||
| Name | Specs | Quantity | Remarks |
| Transparent display | 30" OLED transparent screen | 1 piece | |
| System | Customized to actual needs (built in) | 1 set | |
| Remote control | Universal version (without battery) | 1 | |
| Power cord | Gb 1.5 m | 1 piece | |
| HDMI extension cable | ‑ | 1 stick | Optional |
| Touch USB extension cable | assorting | 1 stick | |
| HDMI signal cable | ‑ | 1 stick | Optional |
| Warranty Card & Certificate of qualification | Chinese Version | 1 sheet | |
| Note: HDMI extension cable, HDMI cable and touch USB extension cable are optional items, the final packing list is subject to the actual shipment of the customer, you can choose whether to configure the extension cable according to the customer's demand, remarks matching will produce the corresponding cost, please confirm the price of shipment. | |||
| Ⅲ、Product Features | |||
| 1. Ultra‑high resolution: up to 1366*768 resolution; 2. High permeability: permeability up to 43%; 3. Intelligent image elimination, with anti‑burn‑in technology, the system automatically starts or closes the image elimination engine, to solve the situation of OLED screen molecules being burned‑in when the still picture, effectively extend the service life of OLED screen; 4. Physical tempered anti‑riot high‑permeability glass; Enhance the visual effect, enhance the touch experience; 5. High‑speed 10‑point touch writing experience, better smoothness, faster writing speed; 6. Built‑in Android/computer system (optional), wireless WIFI, easy to expand; 7. Ultra‑narrow frame, the use of simple and stylish three‑sided appearance design, up and down brushed silver, left and right black frosted material; 8. Dynamic contrast enhancement, through dynamic contrast enhancement technology and local intelligent backlight adjustment technology, improve the image layer; 9. RS232 communication protocol, 1 RS232 input, 2 RS232 output, the control signal can be transmitted in parallel to prevent the attenuation of the control signal due to the number of screens. Through RS232 to obtain large screen status parameters such as interface status, temperature, brightness, contrast, color temperature, etc.; 10. Built‑in intelligent temperature control, can work continuously for 24 hours, the internal temperature of the processor reaches about 45 degrees, the temperature exceeds 50 degrees progress protection mode, the software address can be set by remote control software ID, screen control software support matrix linkage, easy operation, built‑in a variety of matrix protocols. | |||
| Ⅳ、Product size | |||
| ‑(Dimension drawing placement area)‑ | |||
OEM & ODM Industrial Display Manufacturing
Overview
HITULCD has manufactured industrial and commercial display hardware since 2014, currently shipping to 38+ export markets with 120,000+ units of annual production capacity. We support two distinct engagement models — OEM (you own the design, we manufacture to your spec) and ODM (we co-develop or fully design the hardware for you) — covering everything from LCD module bonding and touch integration to complete housing assembly and reliability testing.
This page exists to answer the two questions every serious buyer asks before an RFQ: can this factory actually build to my spec, and what does working with them look like in practice. Below is both.
OEM vs. ODM — Which One Do You Need?
| OEM Mode | ODM Mode | |
|---|---|---|
| Who owns the design | You provide the layout/branding | We participate in layout & structural design |
| Scope | Branding customization, mass production to your drawings | In-depth R&D customization, full structure & software |
| Tooling | Standard tooling, low MOQ | Exclusive mold development |
| Confidentiality | Standard terms | NDA required |
| Typical lead time | 4–6 weeks | 8–16 weeks |
If you already have a layout, brand color spec, and logo files ready — OEM mode gets you to production fastest. If you need us to help design the panel, housing, or embedded software from a functional spec, that's ODM, and it starts with an NDA before any technical exchange.
Customization Checklist (What We'll Ask For)
To scope a quote accurately, have the following ready before you reach out:
Screen size & resolution requirement
Layout / zone division ratio (if display has multiple content regions)
Brand color specification (Pantone/RAL reference)
Font authorization document (if custom fonts are used in firmware/UI)
Logo vector source file (AI/SVG)
Installation method (wall-mounted / embedded / pole-mounted)
Application environment (indoor / outdoor / semi-outdoor)
Certification requirements (CE / FCC / RoHS, etc.)
Sending these upfront typically shortens the quotation cycle by avoiding a second round of clarifying questions.
Manufacturing Capability
Core LCD Module ProductionAutomated COG/FOG bonding lines (JYD-I900E full-automatic COG series, JYD-F900E/F900A atomization bonding system) with micron-level alignment control.
Custom Assembly & Structural IntegrationGH-1111 laser cutting (7.5KW fiber laser), OC-1200A precision glass cutting, full-automatic laminating & gluing lines, PT-A12-B automatic mounter (5.5KW), F6-AS120 ACF laminating machine.
Reliability & Quality Testing2D measuring instruments, HYC-TH-80DH high/low temperature test chambers, microscopes & visual inspection systems, ISO 14644-1 certified cleanroom production.
Production FlowCell feeding → vacuum quenching → ACF attachment → IC alignment & pre-bonding → FOG electrical test → FPC main bonding → FPC alignment & pre-bonding → IC main bonding → ITO encapsulation → high-temperature adhesive & label attachment → visual inspection.
Certifications & Compliance
| Certification | Scope | Status |
|---|---|---|
| CE | European Conformity | Valid until Dec 2027 |
| FCC | US Compliance | Valid until Dec 2027 |
| RoHS | Restriction of Hazardous Substances | Valid until Dec 2027 |
| ISO 9001:2015 | Quality management | Held |
| ISO 14001:2015 | Environmental management | Held |
| IATF 16949:2016 | Automotive quality (relevant for transportation/HMI clients) | Held |
| UL | Product safety | Held |
| REACH | EU chemical compliance | Held |
| WEEE | E-waste directive | Held |
Commercial Terms
Production capacity: 120,000+ units annually
OEM lead time: 4–6 weeks
ODM lead time: 8–16 weeks
MOQ: low for OEM branding customization;
Company Facts
Founded: 2014 (11+ years in operation)
Export markets: 38+
Annual production capacity: 120,000+ units
Legal entity: Shenzhen Hantu Jiashi Technology Co., Ltd. (USCC 91440300306068446B)
Next step: Request a Quote with your customization checklist answers, or reach out first to scope whether OEM or ODM mode fits your program.
30" OLED Transparent Display — Commercial-Grade Transparent Screen
Model: VTS-SZ30L2 (internal reference HT300OL-D01)
Overview
The VTS-SZ30L2 is a 30" commercial-grade OLED transparent display built for applications where the screen itself needs to disappear — retail window displays, museum exhibits, showcase cabinets, and interactive signage. At 1.6mm panel thickness and 43% transmittance, it layers digital content over real objects behind the glass without blocking the view when the display is off.
Unlike LCD-based "transparent" displays that rely on a backlight and lose contrast in bright environments, this is a true self-emissive OLED panel — giving true blacks, 100,000:1 static contrast, and wide 178°/178° viewing angles with no washout at extreme angles.
This unit is manufactured in-house by Shenzhen Hantu Jiashi Technology Co., Ltd. (est. 2014, USCC 91440300306068446B) — no trading company markup, and direct engineering support from the team that designs the panel driver.
Display Specifications
| Parameter | Value |
|---|---|
| Panel size / type | 30" OLED |
| Display area | 664.29 × 373.48 mm |
| Overall dimensions (W×H×D) | 676.09 × 387.48 × 1.6 mm |
| Transmittance | 43% |
| Static contrast | 100,000:1 (Typ.) |
| Dynamic contrast | 200,000:1 (Typ.) |
| Brightness | 200–600 nit (configurable) |
| Resolution | 1366 × 768 |
| Color | 10-bit, 1.07B colors |
| Response time | 8 ms |
| Viewing angle | 178° / 178° |
| Panel lifespan | ≥30,000 hours |
| Power consumption | ≤150 W |
| Screen weight | 1.04 kg |
| Gross shipping weight (packed) | 25kg |
Anti Burn-In & Panel Protection
OLED panels are susceptible to image retention under static content — a common concern for engineers evaluating OLED for signage. This unit addresses it with:
Automatic pixel-shift / image elimination engine that activates on static content
Built-in intelligent temperature control (throttles at ~50°C internal temperature)
Manufacturer-rated for continuous 18-hour/day, 7-day operation
Mechanical & Installation
Frame-sticker mount standard; full-fit mounting available as an option
Ultra-narrow bezel: brushed silver top/bottom, frosted black left/right
Splice seam width: 5.9 mm single-side, 12 mm double-side (for multi-panel video walls)
Environmental & ingress protection:
| Parameter | Value |
|---|---|
| Operating temperature | 1°C – 45°C |
| Operating humidity | 30% – 80% |
| Altitude | 0–5000 m |
| Operating voltage | 100–240VAC, 50/60Hz |
| IP rating (front glass / housing) | contact |
| EMC/EMI compliance class | contact |
Touch (Optional)
| Parameter | Value |
|---|---|
| Technology | Capacitive, 10-point touch |
| Cover glass | 5–8 mm tempered high-transmittance glass |
| Positioning accuracy | 3 mm |
| Response speed | ≤5 ms |
| Rated life | ≥60 million touches |
| Driver requirement | Plug-and-play, no driver install (USB) |
Control & System Integration
Video input: HDMI IN, DP IN
Control: RS232 (RJ45), 1× input / 2× output daisy-chain for multi-screen matrix control without signal degradation
Retrieves live panel status via RS232 — interface state, temperature, brightness, contrast, color temperature
Supports multiple matrix control protocols for large-scale deployment
Video wall processor compatibility: [ Contact The Manufacturer. ]
Onboard compute (optional):
PC module: Intel Core i3/i5/i7 (4th–10th gen), 4/8/16GB DDR3, SSD 120–480GB or HDD 500GB–2TB, Windows 7/10
Android module: RK3288/3399, 2–8GB RAM, 8–64GB storage, WiFi + LAN
Certifications & Compliance
Every unit ships standard with CE, FCC, and RoHS certification. REACH and WEEE compliant. UL/CCC/EAC available on request (additional cost and lead time apply — confirm before ordering).
The factory operates under ISO9001 and complies with local labor law (no child or forced labor, fair working hours); compliance documentation is available on request for ESG due diligence.
Warranty & After-Sales
12-month warranty: remote troubleshooting first, followed by free replacement and expedited reshipment once a hardware fault is confirmed
24/7 engineering support via WhatsApp
[ Clarify before publishing: (1) does warranty cover OLED-specific failure modes such as burn-in/image retention and touch-sensor failure, or only general hardware defects; (2) who covers return shipping/customs on a warranty claim — factory or buyer; (3) is there a regional repair/replacement point, or does every unit ship back to Shenzhen. These three questions come up in nearly every enterprise RFQ and are currently unanswered on the page. ]
Commercial Terms
MOQ: 1 unit for standard specification. Custom brightness, size-cutting, or bezel design may raise MOQ — confirmed at quotation stage, before any deposit.
Lead time: 2–3 weeks (standard), 4–6 weeks (custom), 6–8 weeks (bulk orders 500+ units)
Incoterms: EXW, FOB, CIF
Payment: T/T, L/C, PayPal (samples), O/A (repeat partners)
Production capacity: 12,000+ units/month
Pricing: [ Contact The Manufacturer. ]
Reference Projects
[ Contact The Manufacturer ]
Packing List
| Item | Spec | Qty | Notes |
|---|---|---|---|
| Transparent display | 30" OLED transparent screen | 1 pc | |
| System | Customized to requirement (built-in) | 1 set | |
| Remote control | Universal (battery not included) | 1 | |
| Power cord | 1.5 m | 1 pc | |
| HDMI extension cable | — | 1 | Optional |
| Touch USB extension cable | Assorted | 1 | |
| HDMI signal cable | — | 1 | Optional |
| Warranty card & certificate | Chinese version | 1 sheet | [ Contact The Manufacturer ] |
Next step: Request a quote, or ask for a sample unit before committing to a bulk order — samples are available ahead of full production runs.
Know The Terms Before You Inquire.
No surprises after you send an inquiry. Shipping terms, order minimums and payment protection are all confirmed upfront.
|
01 — Shipping Terms
Incoterms Available
EXW
Ex Works — pick up from our factory
FOB
Free On Board — most common for ocean freight
CIF
Cost, Insurance & Freight — to your port
|
02 — Order Minimum
MOQ: 1 Units
Applies to standard specifications. Custom brightness, size-cutting or bezel design may adjust MOQ — confirmed at quotation stage, not after deposit.
Sample units available before bulk order
|
03 — Payment Protection
Multiple Secured Methods
|
A Real Factory. Publicly Verifiable.
Before you send an inquiry, check us out yourself. All the information below is on public record with Chinese government business registries.
|
Legal Company Name
Shenzhen Hantu Jiashi Technology Co., Ltd.
|
Unified Social Credit Code
91440300306068446B
|
|
Legal Representative
YUN CHEN
|
Registered Capital
RMB 2,000,000
|
|
Established
May 23, 2014 (11+ years in operation)
|
Business Status
● Active / In Operation
|
|
Registered Factory Address
Building B, Gangshen Innovation Park, Huaning Road, Dalang Sub-district, Longhua District, Shenzhen, Guangdong, China
|
|
Contact HITULCD
We'll respond via email within 24 hours. If you'd like to discuss details over WhatsApp or a call, please leave a preferred time and contact method in your message — we will never call you unannounced.
Related solutions
This product is suitable for the following industry application scenarios
Related Products
You may also be interested in the following products
